Specifications
| 29 parameters | Research parameters reported | Sample aspiration |
|---|---|---|
| RBC, MCV, HCT, RDW-CV, HGB, MCH, MCHC, PLT, MPV, , WBC, LYM#, LYM%, MON#, MON%, NEU#, NEU%, EOS#, EOS%, BAS#, BAS% | 9 parameters: RDW-SD, PCT, PDW, P-LCC, P-LCR, AL#, AL%, IG#, IG% | Open tube |
| Throughput | Samples | Sample volume |
| CBC mode: ≥ 64 samples per hour CBC+DIFF mode: ≥ 48 samples per hour | Whole blood (venous and capillary) Pre-dilutes whole blood | CBC mode: ≤ 20 μL CBC+ DIFF mode: ≤ 25 μL |
| Cleaner | Reagents | Interface ports |
| EasyCleaner (50 mL) | Diluent (20 L) Lyse 1 (200 mL) Lyse 2 (500 mL) | 4 USB ports, 1 LAN port that supports bidirectional HL7 protocol |
| Export of parameter results | Quality control | Linearity ranges |
| External laser printer or inkjet printer (various printout formats and user-defined formats) External USB flash disk Laboratory information system (LIS) | Tri-level controls (L, N, H) QC statistics: Mean, SD, CV%, Levey-Jennings and X-bar | PLT: 0–3000 × 109/L RBC: 0–8.5 × 1012/L WBC: 0–300 × 109/L HGB: 0–250 g/L |
| Dimension | Weight | Display |
| 364 mm (L) x 431 mm (W) x 498 mm (H) | 26.5 kg | 10.4 inch TFT touch screen |
