Indiko Plus Features:
- IVDR-compliant, cost-effective solution for small and medium laboratory settings
- Methods used in Indiko Plus are traceable to international reference methods and materials
- Sample oriented testing generates results quickly, enhancing the quality of patient care
- Application protocols include routine clinical chemistry tests as well as special tests, such as specific proteins, drug of abuse testing, therapeutic drug monitoring, and immunosuppressant drug testing
- Simple and quick daily start-up and maintenance procedures
- Continuous access to samples, cuvettes, and reagents without interrupting the testing process
- Disposable cuvettes allow user-safe and contamination-free analysis
- Versatile, automated dilution features make sample processing easier
- Reflex testing capability offers savings in operator time, automatically triggering the specific test to be run
- Measurement reliability can be monitored with a real-time QC program
- Automatic upload of calibrator and control values saves time and reduces manual errors
- Results archiving associated with calibration and reagent lot data secure full traceability
Specifications
- Operating Principle: Fully automated, sample-oriented, random access analyzer
- Capacity: photometric tests/hr: up to 350
- On-board capacity: up to 108 sample positions and 42 reagent positions
- Sample volume: 2 to 120μL
- Reagent volume: 2 to 240μL (1 to 4 reagent additions/test)
- Reaction volume: 120 to 300μL
- Incubator: 9 x 10-position single-use cuvettes, totally 90 cuvette positions
- Photometer: 12 filter positions
- Absorbance range: 0 to 3.5A
- Water consumption: 2.5L/hr.
- Workstation: separate PC
- Bi-directional LIS-connection
- Power consumption: 300w
- Dimensions (L x W x H): 27.6 x 37 x 24.4in. (70 x 94 x 62cm)
- Weight: 242 lb. (110kg)
Parameter
- Test speed: 350 tests/hour
- Sample sites: independent sample tray, can load up to 108 samples (18 samples/rack x 6 sample racks)
- Reagent sites: independent reagent tray can load up to 42 reagents
- Dimensions (width × depth × height) and weight: 94×70×62cm, 110kg
