Description
Patient Management
MS Access Database system allows you to search symptoms, diagnosed information, and related contents. You can also easily manage data and history of patients.
Digital Camera
The IEEE 1394 interface in the Huvitz camera system offers you a high mega pixel resolution images with increased speed and a more stable data transmission than a conventional.
Camera Control
High performance progressive scan CCD camera provides quick image capture of diagnosed images and videos in
real time with a simple click on joystick button.
Specification
| DIGITAL CAMERA | |
|---|---|
| Image Sensor | 1/2” Interline CCD |
| Image Size | up to 1,388 x 1,036 pixels |
| Cell Size | 4.65μm x 4.65μm |
| Resolution Depth | 8bit or 12bit Raw RGB, YUV 4 : 2 : 2 |
| Transmit Method | IEEE 1394 (6pin) |
| Transmit Speed | 400Mbps |
| Frame Rate | 15fps, 7.5fps, 3.75fps |
| Lens Mount | C-Mount |
| Photographing | External Trigger or Software Trigger |
| Dimension | 44mm (W) x 29mm (H) x 63mm (D) |
| Power Consumption | 3W(12V DC, from IEEE 1394 Cable) |
| HIS-5000 | |
| CPU | Pentium IV, 2GHz |
| Memory | 512MB(over 1GB recommended) |
| Video card | ATI Radeon 9200(128MB) or similar |
| System | Microsoft Windows NT(with service pack 6),Windows 2000(with service pack 4) |
| Transmit method | Windows XP, Microsoft internet Explorer 6( Explorer 7 recommended )Standard IEEE 1394a Firewire port OHCI 1.1 Compatible (with auxiliary 12V powerconnector if connected to a laptop computer) |
| Monitor | LCD or CRT (minimum resolution 1,280 x1,024 pixels, over 1,600 x 1,200 pixels recommended) |
| Designs and details can be changed without prior notice for improvements. | |
